Factory wholesale Infrared thermography telescope monocular RS535 thermal imaging Hunting sights thermal camera for hunting

Name: Factory wholesale Infrared thermography telescope monocular RS535 thermal imaging Hunting sights thermal camera for hunting
Rating: 5 (92 reviews)

产品详情

Product Description

RS Thermal Imaging Telescope

RS series infrared thermal imaging sighting device adopts uncooled vanadium oxide detector with core 384x288/640x512 resolution.Max.recoil power can be achieved 800g/ms, Suitable for use in models up to 7.62mm,A must-have for outdoor hunting players

Multiple specifications are available

Core 384x288/640x512 resolution uncooled vanadium oxide detector, 19mm/35mm/50mm lens optional, 50Hz frame rate, built-in 1000m laser ranging module optional, built-in electronic compass and motion sensing, a variety of cross division and custom memory calibration parameters can be set, WiFi real-time transmission, built-in photo and video, 1440x1080 pixel OLED color ultra-clear display, delicate picture, detail enhancement algorithm, Lison II has a clearer picture. IP66 protection

Specification

Items		Technical Parameter
		RS519(L)	RS535(L)	RS635(L)	RS650(L)
Detector	Type	Vox
	Pixel	384x288		640x512
	Pixel Spacing	12 um
	Wavelength range	8-14 um
	NETD	≤35mk
IR Lens	Focus	19mm/F1.0	35mm/F1.0	35mm/F1.0	50mm/F1.0
	FOV	13.8°x10.4°	7.5°x5.7°	12.5°x10.0°	8.8°x7.0°
	Focusing Method	Manual
	Monitor	OLED, 0.39'', 1440x1080
Image Display	Eyepiece Parameter	40 mm
	Magnification	1.77x-7.08x	3.26x-13.04x	1.91x-7.64x	2.72x-10.88x
	Diopter Adjustment	-5D~+5D
	Laser Rangefinder	Can be extended (optional), ranging from 10 to 1000m
	Electronic compass/motion sensor	Support
	WI-FI	Support
Image Performance	Frame Rate	50 Hz
	Image Correction	Auto/Manual
	E-ZOOM	2x, 4x
	Hot Spot Tracking	Support
	Cross Reticle	Support
	Palette	White heat, black heat, iron red, red heat, forests
	Image Transmission	WIFI real-time image transmission, photography, and video
Image Storage	Memory	32 GB
	Photos	Support
	Video	Support
Power System	Battery Type	Single standard 26500 rechargeable lithium battery, replaceable.
	Battery Working Time	＞5h
	Charging Method	Support online charging
	External Power Supply	DC5V/2A
Interface	Data interface	Type-C
	Installation interface	Three standard fixing screw holes, and different optional mounting brackets.
Physical characteristic	Diamension (mm)	≤1658065mm/≤16511065mm （With laser）	≤1908065mm/≤19011065mm （With laser）	≤1908065mm/≤19011065mm（With laser）	≤2008065mm/≤20011065mm （With laser）
	Weight (g)	≤470g/ ≤532g（With laser）	≤520g/ ≤582g（With laser）	≤525g/ ≤587g（With laser）	≤570g/ ≤632（With laser）
Environment Parameter	Working temperature	-30℃~+55℃ （-22°F~131°F）
	Storage temperature	-40℃~+70℃
	Max. Recoil Power	800g/ms
	Capsulation	IP66
Detection distance	Human (1.08x0.5) m	750m	1400m	1400m	1900m
	Car (2.3x2.3) m	1800m	2200m	2200m	3200m
Recognition distance	Human（1.8×0.5）m	367m	700m	700m	1000m
	Car（2.3×2.3）m	910m	1100m	1100m	1600m
