Advanced ports, powerful functions, with extensive use
* With 50Hz frame rate and 1000M/100M/ adaptive Ethernet interface, it supports transmitting real-time on-site temperature data.

* Various back-end interfaces may directly access to monitoring systems in the integration solutions, greatly shortening the R&D
cycle.

* With multiple network protocols including TCP, UDP, ICMP, and DHCP, it can monitor the temperature in real time and give an
alarm in case of any abnormality. It is also compatible with ONVIF, GB28181, and other protocols, easy to install on the site.
Meanwhile, it can share the analysis and alarms easily.

Excellent configuration, more usable than ever
* It is specially optimized for networking and equipped with professional PC software at the back end for the implementation of
1-main-device-to-1-camera or 1-main-device-to-multiple-cameras, so as to reducing cost.

* 20℃~+550℃ wide range temperature measurement makes it possible to monitor more industrial targets requiring high-temperature
measurement.

* It provides lenses of various optional focal lengths. It can output high-quality infrared images and meet the detecting
requirements for space-restricted areas and small targets.

Specification

Dedicated support and concerted effort to forming your own advantages
* Windows/Linux/Android SDKs are available for users' secondary development, which is practical and benefits the users.

* Display the test results of more points, lines, and areas, simplify the data acquisition at the back-end, and facilitate more
flexible applications with reduced cost.

* Support the alarm function and give alarms in case of any abnormality (I/O output, log, image storage, file sending (FTP),
E-mail (SMTP)).

item	value
Warranty	1 years
Customized support	OEM, ODM, OBM, Software reengineering
Place of Origin	SHENZHEN
Brand Name	IRAY
Model Number	AT31
Size	46.54883(mm)
Weight	<150g
Type	Monocular
Magnification	1.0
Effective Visual Distance	1-50m
Operating Voltage	9~26V DC
Items	AT31F
Resolution	384X288
Focal length	4mm,6.2mm,9.7mm,13mm,19mm,25mm,35mm
Focusing method	Fixed focal length
Measuring Range	-20℃~+150℃,0℃~+550℃
Temperature Measurement Accuracy	±2℃ or ±2%
Network Interface	RJ45 10M/100M/1000M self-adapted
Video Format	mp4,mov
Operating Temperature	-20℃~+60℃
Serial Communication Interface	Customizable RS-485, RS-232

Packing & Delivery

carton box
